Using ICE for Optimal Traffic Control Design

By Camie Ferrier, PE, PTOE, Transportation Service Lead, Randy Carroll, PE, Director, Transportation Service, and Paul Villaluz, PE, PTOE, RSP1, DTM, Transportation Senior Project Manager

There are many alternatives to consider when designing a safe and efficient interaction. An Intersection Control Evaluation (ICE) is a highly effective tool for assessing the site and choosing an appropriate design solution.

ICE – What is it?

An Intersection Control Evaluation (ICE) is a performance-based framework that utilizes a data-driven approach and objective metrics to identify, evaluate, and select the appropriate geometric and traffic control solutions for an intersection. ICE is a well-documented and defensible decision-making process that determines the 'best value' geometric design and traffic control, considering multiple factors, including safety, operations, environmental impacts, constructability, and cost. Traditionally, the use of ICE is at the state level. However, more recently, a growing number of municipal transportation agencies have been developing and adopting ICE policies.

ICE – When is it used?

An ICE is used when developing a new intersection or considering substantial changes to an existing intersection. In many cases, state and local governments have adopted policies that define when to conduct an ICE.

Substantial changes that require an ICE often include:

• Safety and/or operational improvements
• Congestion mitigation or broader corridor improvements
• Traffic control changes
• Access to an adjacent parcel of land or development changes

ICE - What's Included?

The ICE process is flexible and scalable, matching the project's complexity level. The level of complexity is consistent with the level of analysis and project type. However, the fundamental principles of ICE are the same. Typically, ICE includes two stages.

Stage I - Scoping

This first step includes defining the project background, purpose, and need and developing a list of possible intersection types and control alternatives. These alternatives are analyzed individually using quantitative and qualitative performance metrics to determine the extent of their potential to meet the project’s objectives and funding constraints.

Stage II - Alternative Selection

This step objectively compares alternatives brought forward from stage I. Evaluations are based on various performance metrics, including safety, operational performance, multi-modal accommodations, environmental and utility impacts, right-of-way impacts, public input, benefit-cost analysis, and practical feasibility. At the completion of stage II, a report is prepared to document the process and the resulting recommendation.

ICE - Benefits

Transportation agencies that have enacted ICE policies realize many important benefits from the process, including:

• Focus on safety in the decision-making process
• Implementation of more cost-effective solutions
• Consistent documentation and transparency
• Increased awareness of innovative solutions
• Emphasis on objective performance metrics for consistency
• Consolidation and streamlining of existing intersection-related policies

Our transportation team has completed numerous Intersection Control Evaluations for state and local government entities across the county. If you have questions or would like more information, contact our experts.

....
